High way W-beam
Item No.: SR/HG-W1
W-beam Panel is a kind of road crash barrier used for securing highway safety by preventing errant vehicles from sliding out of the roads and impacting the roadside buildings or other objects. So it is most commonly fixed on the side of the highways, d
Description
| Standard Size | 4120mm*310mm*85mm , 7920mm*310mm*85mm or customized |
| Material | Q235,Q355, S355JR |
| Base metal nominal thickness | 2.67mm, 3.43mm or customized |
| Surface Treatment | Hot dip galvanized as per ASTM A653 |
| Zinc coating thickness | Type I: 550g/m2, Type II: 1100g/m2, or customized |
| Standards | AASHTO M180 |
| Application | Highway, High grade roads. |
We manufacture highway guardrails according to the Standards as below:
A. GB/T31439-2015 (Corrugated Sheet Steel Beams For Expressway Guardrail - China)
B. AASHTO-M180 (Corrugated Sheet Steel Beams For Highway Guardrail - USA)
C. AS/NZS 3845:1999 (Road Safety Barrier Systems - Australia/New Zealand)
D. EN-1317 (Road Restraint Systems - Europe)
E. Or tailor-make according to client's requirements
